DataSheet

50HZ

60HZ

  TANK 6370 TANK 8370
Discharge Outlet 150 mm (6") 200 mm (8")
Shaft Speed 2850 rpm 2850 rpm
Rated Output 37 kW (50 HP) 37 kW (50 HP)
Rated Head 60 m (197') 40 m (131')
Rated Flow 33.3 L/s (528 gpm) 60 L/s (950 gpm)
Max Head 90 m (295') 50 m (164')
Max Flow 41.6 L/s (660 gpm) 91.6 L/s (1452 gpm)
Solid Passage 10 mm (0.4") 20 mm (0.8")
Diameter 532 mm (20.9") 532 mm (20.9")
Height 1294 mm (50.9") 1256 mm (49.4")
Weight 510 kg (1124 lbs) 510 kg (1124 lbs)
  TANK 6370 TANK 8370
Discharge Outlet 150 mm (6") 200 mm (8")
Shaft Speed 3450 rpm 3450 rpm
Rated Output 37 kW (50 HP) 37 kW (50 HP)
Rated Head 60 m (197') 40 m (131')
Rated Flow 33.3 L/s (528 gpm) 60 L/s (951 gpm)
Max Head 90 m (295') 55 m (180')
Max Flow 41.7 L/s (660 gpm) 83.3 L/s (1321 gpm)
Solid Passage 10 mm (0.4") 20 mm (0.8")
Diameter 532 mm (20.9") 532 mm (20.9")
Height 1294 mm (50.9") 1256 mm (49.4")
Weight 510 kg (1124 lbs) 510 kg (1124 lbs)
