DataSheet

50HZ

60HZ

  X16-VOX 208 X16-VOX 215
Discharge Outlet 50 mm (2") 50 mm (2")
Shaft Speed 2850 rpm 2850 rpm
Rated Output 0.75 kW (1 HP) 1.5 kW (2 HP)
Rated Head 7 m (23') 14 m (46')
Rated Flow 3.3 L/s (53 gpm) 3.3 L/s (53 gpm)
Max Head 12.5 m (41') 18 m (59')
Max Flow 5.5 L/s (87 gpm) 7.7 L/s (121 gpm)
Solid Passage 40 mm (1.6") 37 mm (1.5")
Diameter 233 mm (9.2") 233 mm (9.2")
Height 415 mm (16.3") 445 mm (17.5")
Weight 12 kg (26 lbs ) 15 kg (33 lbs)
