STORMY 75P

DataSheet

50Hz
  STORMY 475P
Discharge Outlet 100 mm (4")
Shaft Speed 1450 rpm
Rated Output 7.5 kW (10 HP)
Rated Head 14 m (46')
Rated Flow 20 L/s (317 gpm)
Max Head 18.5 m (61')
Max Flow 41.3 L/s (655 gpm)
Solid Passage 25 mm (1")
Diameter 420 mm (16.5")
Height 826 mm (32.5")
Weight 124 kg (273 lbs)
60Hz
  STORMY 475P
Discharge Outlet 100 mm (4")
Shaft Speed 1750 rpm
Rated Output 7.5 kW (10 HP)
Rated Head 14 m (46')
Rated Flow 20 L/s (317 gpm)
Max Head 18.5 m (61')
Max Flow 41.3 L/s (655 gpm)
Solid Passage 25 mm (1")
Diameter 420 mm (16.5")
Height 826 mm (32.5")
Weight 124 kg (273 lbs)

Download File

Brochure - Slurry & Sand Pumps 50 Hz 60 Hz
Datasheet - STORMY 475P 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 4 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Opened
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 10m (33') or longer upon request.
Materials
 • Pump Casing Ductile Iron
 • Impeller Chromium Iron
 • Motor Frame Gray Iron
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
