X-SMART 400

DataSheet

50Hz
  X-SMART 400
Discharge Outlet 50 mm (2")
Shaft Speed 2850 rpm
Rated Output 0.4 kW (0.5 HP)
Rated Head 7 m (23')
Rated Flow 2.3 L/s (37 gpm)
Max Head 10 m (33')
Max Flow 4 L/s (63 gpm)
Solid Passage 5.5 mm (0.2")
Diameter 180 mm (7.1")
Height 333 mm (13.1)
Weight 13 kg (29 lbs)
60Hz
  X-SMART 400
Discharge Outlet 50 mm (2")
Shaft Speed 3450 rpm
Rated Output 0.4 kW (0.5 HP)
Rated Head 7 m (23')
Rated Flow 2.3 L/s (37 gpm)
Max Head 10 m (33')
Max Flow 4 L/s (63 gpm)
Solid Passage 5.5 mm (0.2")
Diameter 180 mm (7.1")
Height 333 mm (13.1")
Weight 13 kg (29 lbs)

Download File

Brochure - Stainless Steel Pumps 50 Hz 60 Hz
Datasheet - X-SMART 400 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 1-Phase,3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method 1-Phase • Capacitor-Run,3-Phase • D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Opened
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 6m (20') or longer upon request.
Materials
 • Pump Casing Stainless Steel
 • Impeller Stainless Steel
 • Motor Frame Stainless Steel
 • Motor Shaft Stainless Steel
 • Strainer Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
