X-VOX 8

DataSheet

50Hz
  X-VOX 208
Discharge Outlet 50 mm (2")
Shaft Speed 2850 rpm
Rated Output 0.75 kW (1 HP)
Rated Head 7 m (23')
Rated Flow 3.3 L/s (53 gpm)
Max Head 12.5 m (41')
Max Flow 5.5 L/s (87 gpm)
Solid Passage 40 mm (1.6) "
Diameter 233 mm (9.2")
Height 415 mm (16.3")
Weight 12 kg (26 lbs )
60Hz
  X-VOX 208
Discharge Outlet 50 mm (2")
Shaft Speed 3450 rpm
Rated Output 0.75 kW (1 HP)
Rated Head 7 m (23')
Rated Flow 3.3 L/s (53 gpm)
Max Head 12.5 m (41')
Max Flow 5.5 L/s (87 gpm)
Solid Passage 40 mm (1.6")
Diameter 233 mm (9.2")
Height 415 mm (16.3")
Weight 12 kg (26 lbs)

Download File

Brochure - Stainless Steel Pumps 50 Hz 60 Hz
Datasheet - X-VOX 208 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 1-Phase,3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method 1-Phase • Capacitor-Run,3-Phase • D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbon VS Ceramic / Carbon
Impeller Type Vortex
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 6m (20') or longer upon request.
Materials
 • Pump Casing Stainless Steel
 • Impeller Stainless Steel
 • Motor Frame Stainless Steel
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
