TANK SLIM 230

DataSheet

50Hz
  TANK SLIM 230
Discharge Outlet 50 mm (2")
Shaft Speed 2850 rpm
Rated Output 3 kW (4 HP)
Rated Head 30 m (98')
Rated Flow 3.3 L/s (53 gpm)
Max Head 35 m (115')
Max Flow 8.3 L/s (132 gpm)
Solid Passage 7 mm (0.3")
Diameter 188 mm (7.4")
Height 659 mm (25.9")
Weight 45 kg (99 lbs)
60Hz
  TANK SLIM 230
Discharge Outlet 50 mm (2")
Shaft Speed 3450 rpm
Rated Output 3 kW (4 HP)
Rated Head 30 m (98')
Rated Flow 3.3 L/s (53 gpm)
Max Head 35 m (115')
Max Flow 8.3 L/s (132 gpm)
Solid Passage 7 mm (0.3")
Diameter 188 mm (7.4")
Height 659 mm (25.9")
Weight 45 kg (99 lbs)

Download File

Brochure - Dewatering Pumps 50 Hz 60 Hz
Datasheet - TANK SLIM 230 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Closed • Dual impellers
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07BQ-F
 • Length 10m (33') or longer upon request.
Materials
 • Pump Casing Gray Iron
 • Impeller Chromium Iron
 • Motor Frame Stainless Steel
 • Motor Shaft Stainless Steel
 • Outer Case Stainless Steel
 • Strainer Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
