TANK 22

With a compact, slim design and the patented ACrS technology, these wear-resistant, portable dewatering pumps provide reliable and economical solutions.

DataSheet

50Hz

	TANK 222	TANK 322	TANK 422
Discharge Outlet	50 mm (2")	80 mm (3")	100 mm (4")
Shaft Speed	2850 rpm	2850 rpm	2850 rpm
Rated Output	2.2 kW (3 HP)	2.2 kW (3 HP)	2.2 kW (3 HP)
Rated Head	15 m (49')	10 m (33')	10 m (33')
Rated Flow	5 L/s (79 gpm)	8.3 L/s (132 gpm)	10 L/s (158 gpm)
Max Head	26 m (85')	20.5 m (67')	15 m (49')
Max Flow	8.3 L/s (132 gpm)	11.7 L/s (185 gpm)	16.7 L/s (264 gpm)
Solid Passage	9 mm (0.4")	9 mm (0.4")	9 mm (0.4")
Diameter	253 mm (10")	267 mm (10.5")	284 mm (11.2")
Height	598 mm (23.5")	598 mm (23.5")	630 mm (24.8")
Weight	35 kg (77 lbs)	35 kg (77 lbs)	43 kg (95 lbs)

60Hz

	TANK 222	TANK 322	TANK 422
Discharge Outlet	50 mm (2")	80 mm (3")	100 mm (4")
Shaft Speed	3450 rpm	3450 rpm	3450 rpm
Rated Output	2.2 kW (3 HP)	2.2 kW (3 HP)	2.2 kW (3 HP)
Rated Head	18 m (59')	10 m (33')	10 m (33')
Rated Flow	5 L/s (79 gpm)	10 L/s (159 gpm)	10 L/s (158 gpm)
Max Head	27 m (89')	20.5 m (67')	15 m (49')
Max Flow	9.3 L/s (148 gpm)	13.3 L/s (211 gpm)	16.7 L/s (264 gpm)
Solid Passage	9 mm (0.4")	9 mm (0.4")	9 mm (0.4")
Diameter	253 mm (10")	267 mm(10.5")	284 mm (11.2")
Height	598 mm (23.5")	598 mm (23.5")	630 mm (24.8")
Weight	35 kg (77 lbs)	35 kg (77 lbs)	43 kg (95 lbs)

Download File

Specifications
