SAVVY JUMBO 300

DataSheet

50Hz
  SAVVY JUMBO 300
Discharge Outlet 50 mm (2")
Shaft Speed 2850 rpm
Rated Output 0.25 kW (0.33 HP)
Rated Head 4 m (13')
Rated Flow 2.2 L/s (34 gpm)
Max Head 7 m (23')
Max Flow 3.7 L/s (58 gpm)
Solid Passage 35 mm (1.4")
Diameter 245 mm (9.6")
Height 337 mm (13.3")
Weight 4.2 kg (9 lbs)
60Hz
  SAVVY JUMBO 300
Discharge Outlet 50 mm (2")
Shaft Speed 3450 rpm
Rated Output 0.25 kW (0.33 HP)
Rated Head 4 m (13')
Rated Flow 2.2 L/s (34 gpm)
Max Head 7 m (23')
Max Flow 3.7 L/s (58 gpm)
Solid Passage 35 mm (1.4")
Diameter 245 mm (9.6")
Height 337 mm (13.3")
Weight 4.2 kg (9 lbs)

Download File

Brochure - Handy & Residue Pumps 50 Hz 60 Hz
Datasheet - SAVVY JUMBO 300 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 1-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Miniature Thermal Protector
 • Start Method Capacitor-Run
Lubricant Food Grade (ISO VG115)
Shaft Seal
 • Type Single Mechanical Seal
 • Desc. Ceramic / Carbon
Impeller Type Vortex
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H05RN-F
 • Length 3m (10') or longer upon request.
Materials
 • Pump Casing Synthetic Polymers
 • Impeller Synthetic Polymers
 • Motor Frame Stainless Steel
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 10m (33")
pH Range pH 5 - pH 8
