SAVVY BASE 300

DataSheet

50Hz
  SAVVY BASE 300
Discharge Outlet 25 mm (1")
Shaft Speed 2850 rpm
Rated Output 0.25 kW (0.33 HP)
Rated Head 4 m (13')
Rated Flow 0.9 L/s (15 gpm)
Max Head 6.5 m (21')
Max Flow 1.3 L/s (21 gpm)
Solid Passage 2 mm (0.1")
Diameter 244 mm (9.6")
Height 304 mm (12")
Weight 4 kg (9 lbs)
60Hz
  SAVVY BASE 300
Discharge Outlet 25 mm (1")
Shaft Speed 3450 rpm
Rated Output 0.25 kW (0.33 HP)
Rated Head 6 m (20')
Rated Flow 0.8 L/s (13 gpm)
Max Head 8 m (26')
Max Flow 1.5 L/s (24 gpm)
Solid Passage 2 mm (0.1")
Diameter 244 mm (9.6")
Height 304 mm (12")
Weight 4 kg (9 lbs)

Download File

Brochure - Handy & Residue Pumps 50 Hz 60 Hz
Datasheet - SAVVY BASE 300 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 1-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Miniature Thermal Protector
 • Start Method Capacitor-Run
Lubricant Food Grade (ISO VG115)
Shaft Seal
 • Type Single Mechanical Seal
 • Desc. Ceramic / Carbon
Impeller Type Vortex
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H05RN-F
 • Length 3m (10') or longer upon request.
Materials
 • Pump Casing Synthetic Polymers
 • Impeller Synthetic Polymers
 • Motor Frame Stainless Steel
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 10m (33")
pH Range pH 5 - pH 8
