GOCUT 15

Designed for handling raw sewage and various wastewater treatments, the cutting mechanism shreds fibrous materials into small pieces to prevent from clogging.

DataSheet

50Hz

	GOCUT 215	GOCUT 315
Discharge Outlet	50 mm (2")	80 mm (3")
Shaft Speed	2850 rpm	2850 rpm
Rated Output	1.5 kW (2 HP)	1.5 kW (2 HP)
Rated Head	8 m (26')	8 m (26')
Rated Flow	5.8 L/s (92 gpm)	6.7 L/s (106 gpm)
Max Head	16 m (52')	16 m (52')
Max Flow	8.3 L/s (132 gpm)	10.8 L/s (172 gpm)
Solid Passage	27 mm (1.1")	27 mm (1.1")
Diameter	301 mm (11.9")	301 mm (11.9")
Height	463 mm (18.2")	463 mm (18.2")
Weight	27 kg (60 lbs)	27 kg (60 lbs)

60Hz

	GOCUT 215	GOCUT 315
Discharge Outlet	50 mm (2")	80 mm (3")
Shaft Speed	3450 rpm	3450 rpm
Rated Output	1.5 kW (2 HP)	1.5 kW (2 HP)
Rated Head	9 m (30')	8 m (26')
Rated Flow	6 L/s (95 gpm)	7.2 L/s (114 gpm)
Max Head	17 m (56')	16 m (52')
Max Flow	8.3 L/s (132 gpm)	10 L/s (159 gpm)
Solid Passage	27 mm (1.1")	27 mm (1.1")
Diameter	301 mm (11.9")	301 mm (11.9")
Height	463 mm (18.2")	463 mm (18.2")
Weight	27 kg (60 lbs)	27 kg (60 lbs)

Download File

Specifications
