GOVOX-G 55

DataSheet

50Hz
  GOVOX-G 455
Discharge Outlet 100 mm (4")
Shaft Speed 2850 rpm
Rated Output 5.5 kW (7.5 HP)
Rated Head 17 m (56')
Rated Flow 12 L/s (190 gpm)
Max Head 29 m (95')
Max Flow 22.5 L/s (356 gpm)
Solid Passage 52 mm (2")
Diameter 464 mm (18.3")
Height 695 mm (25.4")
Weight 73 kg (161 lbs)
60Hz
  GOVOX-G 455
Discharge Outlet 100 mm (4")
Shaft Speed 3450 rpm
Rated Output 5.5 kW (7.5 HP)
Rated Head 18 m (59')
Rated Flow 12.5 L/s (198 gpm)
Max Head 29 m (95')
Max Flow 22.5 L/s (357 gpm)
Solid Passage 52 mm (2")
Diameter 464 mm (18.3")
Height 695 mm (25.4")
Weight 73 kg (161 lbs)

Download File

Brochure - Sewage Pumps 50 Hz 60 Hz
Datasheet - GOVOX-G 455 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbon VS Ceramic / Carbon
Impeller Type VorteX
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 10m (33') or longer upon request.
Materials
 • Pump Casing Gray Iron
 • Impeller Gray Iron
 • Motor Frame Gray Iron
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
