GOVOX 4

DataSheet

50Hz
  GOVOX 204
Discharge Outlet 50 mm (2")
Shaft Speed 2850 rpm
Rated Output 0.4 kW (0.5 HP)
Rated Head 5 m (16')
Rated Flow 2 L/s (32 gpm)
Max Head 8 m (26')
Max Flow 4.2 L/s (66 gpm)
Solid Passage 32 mm (1.3")
Diameter 243 mm (9.6")
Height 395 mm (15.6")
Weight 14 kg (31 lbs)
60Hz
  GOVOX 204
Discharge Outlet 50 mm (2")
Shaft Speed 3450 rpm
Rated Output 0.4 kW (0.5 HP)
Rated Head 5 m (16')
Rated Flow 2 L/s (32 gpm)
Max Head 8 m (26')
Max Flow 4.2 L/s (66 gpm)
Solid Passage 32 mm (1.3")
Diameter 243 mm (9.6")
Height 395 mm (15.6")
Weight 14 kg (31 lbs)

Download File

Brochure - Sewage Pumps 50 Hz 60 Hz
Datasheet - GOVOX 204 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 1-Phase,3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method 1-Phase • Capacitor-Run,3-Phase • D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Vortex
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 6m (20') or longer upon request.
Materials
 • Pump Casing Gray Iron
 • Impeller Gray Iron
 • Motor Frame Gray Iron
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
