GOSPIN 22

DataSheet

50Hz
  GOSPIN 322
Discharge Outlet 80 mm (3")
Shaft Speed 2850 rpm
Rated Output 2.2 kW (3 HP)
Rated Head 10 m (33')
Rated Flow 10 L/s (158 gpm)
Max Head 21 m (69')
Max Flow 13.3 L/s (211 gpm)
Solid Passage 9 mm (0.4")
Diameter 522 mm (20.6")
Height 613 mm (24.1")
Weight 51 kg (112 lbs)
60Hz
  GOSPIN 322
Discharge Outlet 80 mm (3")
Shaft Speed 3450 rpm
Rated Output 2.2 kW (3 HP)
Rated Head 10 m (33')
Rated Flow 10 L/s (159 gpm)
Max Head 22 m (72')
Max Flow 11.7 L/s (185 gpm)
Solid Passage 9 mm (0.4")
Diameter 522 mm (20.6")
Height 613 mm (24.1")
Weight 51 kg (112 lbs)

Download File

Brochure - Sewage Pumps 50 Hz 60 Hz
Datasheet - GOSPIN 322 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Semi-Open
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 10m (33') or longer upon request.
Materials
 • Pump Casing Gray Iron
 • Impeller Gray Iron
 • Motor Frame Gray Iron
 • Motor Shaft Stainless Steel
 • Strainer Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
