GOVOX-U 37

DataSheet

50Hz
  GOVOX-U 337
Discharge Outlet 80 mm (3")
Shaft Speed 2850 rpm
Rated Output 3.7 kW (5 HP)
Rated Head 15 m (49')
Rated Flow 7.5 L/s (119 gpm)
Max Head 18 m (59')
Max Flow 20 L/s (317 gpm)
Solid Passage 55 mm (2.2")
Diameter 376 mm (14.8")
Height 717 mm (28")
Weight 49 kg (108 lbs)
60Hz
  GOVOX-U 337
Discharge Outlet 80 mm (3")
Shaft Speed 3450 rpm
Rated Output 3.7 kW (5 HP)
Rated Head 15 m (49')
Rated Flow 7.5 L/s (119 gpm)
Max Head 18 m (59')
Max Flow 20 L/s (317 gpm)
Solid Passage 55 mm (2.2")
Diameter 376 mm (14.8")
Height 717 mm (28")
Weight 49 kg (108 lbs)

Download File

Brochure - Sewage Pumps 50 Hz 60 Hz
Datasheet - GOVOX-U 337 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Vortex
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 10m (33') or longer upon request.
Materials
 • Pump Casing Ductile Iron
 • Impeller Ductile Iron
 • Motor Frame Gray Iron
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
