GOVOX 15

DataSheet

50Hz
  GOVOX 315
Discharge Outlet 80 mm (3")
Shaft Speed 2850 rpm
Rated Output 1.5 kW (2 HP)
Rated Head 10 m (33')
Rated Flow 5 L/s (79 gpm)
Max Head 15 m (49')
Max Flow 9.2 L/s (145 gpm)
Solid Passage 50 mm (2")
Diameter 302 mm (11.9")
Height 501 mm (19.7")
Weight 24 kg (53 lbs)
60Hz
  GOVOX 315
Discharge Outlet 80 mm (3")
Shaft Speed 3450 rpm
Rated Output 1.5 kW (2 HP)
Rated Head 10 m (33')
Rated Flow 5 L/s (79 gpm)
Max Head 15 m (49')
Max Flow 10.8 L/s (172 gpm)
Solid Passage 50 mm (2")
Diameter 302 mm (11.9")
Height 501 mm (19.7")
Weight 24 kg (53 lbs)

Download File

Brochure - Sewage Pumps 50 Hz 60 Hz
Datasheet - GOVOX 315 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 1-Phase,3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method 1-Phase • Capacitor-Run,3-Phase • D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Vortex
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 6m (20') or longer upon request.
Materials
 • Pump Casing Gray Iron
 • Impeller Gray Iron
 • Motor Frame Gray Iron
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
