GOFLOW 22

DataSheet

50Hz
  GOFLOW 322
Discharge Outlet 80 mm (3")
Shaft Speed 2850 rpm
Rated Output 2.2 kW (3 HP)
Rated Head 10 m (33')
Rated Flow 10 L/s (158 gpm)
Max Head 18 m (59')
Max Flow 15 L/s (238 gpm)
Solid Passage 27 mm (1.1")
Diameter 482 mm (19")
Height 642 mm (25.3")
Weight 55 kg (121 lbs)
60Hz
  GOFLOW 322
Discharge Outlet 80 mm (3")
Shaft Speed 3450 rpm
Rated Output 2.2 kW (3 HP)
Rated Head 10 m (33')
Rated Flow 10 L/s (159 gpm)
Max Head 18 m (59')
Max Flow 15 L/s (238 gpm)
Solid Passage 27 mm (1.1")
Diameter 482 mm (19")
Height 642 mm (25.3")
Weight 55 kg (121 lbs)

Download File

Brochure - Sewage Pumps 50 Hz 60 Hz
Datasheet - GOFLOW 322 50 Hz 60 Hz

Specifications

Type Electric Submersible Pumps
Phase 3-Phase
Classification IP 68
Motor
 • Type Induction Motor
 • Poles 2 Pole
 • Insulation Class F
 • Protector Circle Thermal Protector
 • Start Method D.O.L.
Lubricant Food Grade (ISO VG32)
Shaft Seal
 • Type Double Mechanical Seal
 • Desc. Silicon Carbide VS Ceramic / Carbon
Impeller Type Semi-Open Channel
Bearings C3 Shielded ball bearings
Cable
 • Type PVC (CSA Certified) / H07RN-F
 • Length 10m (33') or longer upon request.
Materials
 • Pump Casing Gray Iron
 • Impeller Gray Iron
 • Motor Frame Gray Iron
 • Motor Shaft Stainless Steel
Max. Liquid Temp. 40˚C (104˚F)
Max. Sub. Depth 20m (66")
pH Range pH 5 - pH 8
